3003 Aluminium Coil Alloy Strip 3000 Series Customized 0.2mm
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | haiwo |
| Model Number | 3003 |
| Minimum Order Quantity | 1000 kilograms |
| Price | $3.00/kilograms |
| Packaging Details | Export standard package: bundled ,wooden box, suit for all kinds of transport,or be required |
| Delivery Time | 10-45 work days |
| Payment Terms | T/T |
| Supply Ability | 25000 Ton/Tons per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 3003 Aluminium Coil | Grade | 3000 Series |
|---|---|---|---|
| Temper | O-H112,T3-38,T351-T851 | Thickness | 0.006-0.2mm,45-140mic,12/15/18/20 Mic,1.0-12.0mm,70mic~100μm |
| Treatment | Coated,Composited,Other,Embossed,mill Finish | Packing | Wooden Cases,Carton,Wooden Box,Standard Packing |
| High Light | Aluminium Coil Alloy Strip,3003 Aluminium Alloy Strip,Aluminium Alloy Strip 0.2mm |
||
You can tick the products you need and communicate with us in the message board.
| Application | Widely Used, Food packing, manufacture, aluminum foil Pull Tab Strip for milk carton cap, High Temperature | |
|---|---|---|
| Sample | available and free, Free, Can be supplied, customized | |
| Certification | ISO, FDA, ISO9001, SGS, ASTM B209 | |
| Loading port | SHANGHAI PORT |
Product Description
3003 Aluminium Coil Alloy 3000 Series Customized Aluminium Strip
Aluminum coil is widely used in electronics, packaging, construction, machinery and other aspects, China's aluminum coil production enterprises, the production process has caught up with the developed countries, according to the metal elements aluminum coil contains, aluminum coil can be divided into 9 major: 1000 series; The 2000 series; The 3000 series; The 4000 series; The 5000 series; The 6000 series; The 7000 series; The 8000 series; The 9000 series.
Application:1. For constructional exterior curtain walls, aluminum composite panel. 2. Widely used in exhibition, stores, offices, banks, hotels, restaurants and apartments. 3. Decorative renovation for storey-added old buildings, facades, roofing. 4. Indoors decoration for interior walls, ceilings, bathrooms, kitchens, balconies and subway. 5. Advertisement board, display platforms, billboards and signboards. 6. Wallboard and ceilings for tunnels. 7. Raw materials in industrial purpose. 8. Material used for vehicle bodies, yachts and boat.9.Aluminum strip has many uses, such as: aluminum plastic composite pipe, cable, optical cable, transformer, heater, shutter and so on.
Specification
|
Brand
|
Old brand
|
Si
|
Fe
|
Cu
|
Mn
|
Mg
|
Cr
|
Zn
|
Ti
|
|
3003
|
----
|
0.6
|
0.7
|
0.05-0.2
|
1.0-1.5
|
--
|
--
|
0.1
|
--
|
Quality Characteristics
|
Brand
|
Tensile strength
|
Yield strength
|
Hardness
|
Elongation
|
|
3003
|
≥140-200Mpa
|
≥115MPa
|
HB35-45
|
12
|
| Aluminium Coil / Aluminium Alloy Coil | ||
| 1 | Production Standard | ASTM, AISI,EN,DIN,BS,JIS,GOST,GB,etc |
| 2 | Material |
a) 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. g)7000 Series:7075,7475 |
| 3 | Width | 20mm-2500mm or as the customer’s request |
| 4 | Length/weight | Length:Any length. weight:50-10000kg/coil, As the customer’s request |
| 5 | Thickness | Sheet:0.05-10mm; Foil:0.001-0.5 ; Strip:0.01-3mm |
| 6 | Size error | Thickness error:±0.005mm Width error:0.1mm |
| 7 | Surface | Coated, Mill, Bright, Polished, Embossed,Brushed, Anodized,sand blast, checkered,embossed, etching,etc |
| 8 | Temper |
O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc. |
| 9 | OEM service | Perforated, Cutting special size, Doing flatness, Surface treatment,etc |
| 10 | Payterm | EXW, FOB, CIF , CFR, etc |
| 11 | Payment | T/T, L/C, Western Union, etc |
| 12 | Delivery Time | Within 3 days for our stock size,10-20days for our production |
| 13 | Package |
Export standard package: bundled ,wooden box, suit for all kinds of transport, or be required |
| 14 | MOQ | 10kg |
| 15 | Sample | Free and available |
| 16 | Quality |
Mill Test Certification is supplied with shipment,Third Part Inspection(SGS/ROHS Certificate of Test) is acceptable. Tension levelled ,flat ,Free of defects like oil stain,Roll Marks,Waves,Dents scratches etc ,A+++ quality passed sgs and bv inspection |
| 17 | Application |
Construction filed, Ships building industry, Decoration, Industry,Manufacture, Machinery and hardware fields, etc |
| Mechanical Property | ||||||||
| ALUMINUM ALLOY |
Grade | Normal Temper |
Temper | Tensile Strength N/mm² |
Yield Strength N/mm² |
Elongation% | Brinell Hardness HB |
|
| Plate | Bar | |||||||
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |
| Al-Cu (2XXX) |
2017 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 | |
| Al-Mn (3XXX) |
3003 | O,H112,H | O | 110 | 40 | 30 | 37 | 28 |
| 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 | |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg (5XXX) |
5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| 5083 | O,H112,H | O | 290 | 145 | - | 20 | - | |
| Al-Mg-Si (6XXX) |
6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 | |
| Al-Zn-Mg (7XXX) |
7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 | |
FAQ
Q1: How do we trust your company?
A: We specialise in steel production and sales for years as golden supplier on Alibaba, headquarters locates in WUXI, JIANGSU Province, you are welcome to investigate in any ways, by all means, you could place an order in Alibaba with trade assurance which could secure your payment.
Q2: How can we guarantee quality?
A: 1 ). We can provide samples for free.We can send the samples by TNT,DHL,FEDEX,EMS,UPS or to your warehouse. 2 ). Always a pre-production sample before mass production. 3 ). Always final Inspection before shipment.
Q3: Do you have products in stock?
A: There are 10000 tons stock for various size.plsease inform us what model you need, we will send stock details to you.
Q4: How long will it take to produce my order?
A: Our normal produce time is 7-25 working days,depend on your order.
Q5: How much will the shipping cost be?
A: This will depend on the size and weight of your order and the method of shipping.
Q6: Can you help me find the shipping company?
A: Of course, if you don't work with a shipping company.We have a long-term cooperation of the transport team can provide you with lower prices, better service.
Q7: Will our goods be damaged during the long-distance transport? How to avoid it?
A: No damage, we will affix a low viscosity protective film on the surface of the product, effectively avoid scratches, easy to uncover when using, and will not leave stains on the surface.For long distance transportation we have professional experience,familiar with the packaging and arrangement of the goods, let the goods safely arrive at your destination.
Q8: Why should you buy from us not from other suppliers?
A: 1 ). Source manufacturers, leading equipment, excellent team skills. 2 ). Low price, fast delivery and excellent quality, good service. 3 ). Professional technical solution.
