6A02 AISI 10mm Square Aluminium Bar H14 Alloy Aluminum Rod DIN
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | haiwo |
| Model Number | 6061 |
| Minimum Order Quantity | 1000 kilograms |
| Price | $3.00/kilograms |
| Packaging Details | Export standard package: bundled ,wooden box, suit for all kinds of transport,or be required |
| Delivery Time | 10-45 work days |
| Payment Terms | T/T |
| Supply Ability | 25000 Ton/Tons per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 6061 Alloy Aluminum Rod | Grade | 6000 Series |
|---|---|---|---|
| Hardness | 90-110 | Yield (≥ MPa) | 276 |
| Ultimate Strength (≥ MPa) | 310 | Application | Engineering, Turning, Parts, Mechanical Processing |
| Temper | O - H112, T3-T8 | Standard | ASTM,DIN,EN,GB,JIS,GOST |
| High Light | 6A02 10mm Square Aluminium Bar,AISI 10mm Square Aluminium Bar,H14 Alloy Aluminum Rod |
||
You can tick the products you need and communicate with us in the message board.
| Shape | Round, rod, Rectangular, flat, Square | |
|---|---|---|
| Alloy or not | Is Alloy | |
| Technique | Extruded, Cold Drawn, Forging | |
| Surface treatment | Mill Finish, Anodizing, Polished, Brushing |
Product Description
6061 Alloy Aluminum Rod Manufacturer Round Square Aluminum Bar For Window And Door
Aluminum rod is a kind of aluminum products. The melting and casting process of aluminum rod includes melting, purification, impurity removal, gas removal, slag removal and casting.There are about eight main categories of aluminum rods, depending on the metals they contain:1000series,2000series,3000series,4000series,5000series,6000series,7000series,8000series.
Applications: 1. Extrusion coils for food, chemical and brewing industries, various hoses, fireworks powder. 2. It is used in situations requiring high strength and hardness (including high temperature). Aircraft heavy, forgings, plates and extruded materials, wheels and structural elements, first stage rocket fuel tanks and spacecraft parts, truck frames and suspension system parts.3. It IS USED FOR processing parts that need good formability, high corrosion resistance and good weldability, such as kitchen utensils, food and chemical products handling and storage devices, tanks and tanks for transporting liquid products. 4. Used as conductor, cooker, instrument panel, shell and building decoration. And so on.
Specification
|
Garde
|
Si
|
Fe
|
Cu
|
Mn
|
Mg
|
Cr
|
Zn
|
Ti
|
Al
|
|
6061
|
0.4-0.8
|
0.7
|
0.15-0.4
|
0.15
|
0.8-1.2
|
0.04-0.35
|
0.25
|
0.15
|
remains
|
Quality Characteristics
| Brand | Tensile strength | Yield strength | Hardness | Elongation |
| 6061 | ≥310Mpa | ≥276MPa | HB90-110 | 11 |
| Aluminium Bar/Aluminum Flat Bar /Aluminum Square Bar/ Rod | ||
| 1 | Production Standard | ASTM, AISI,EN,DIN,JIS,GOST,GB,etc |
| 2 | Material |
a) 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. g)7000 Series:7075,7475 |
| 3 | Outer diameter | 10mm-800mm |
| 4 | Length | 50mm-12000mm or cut as the customer’s request |
| 5 | Shape | Round, Square, Rectangular, Oval, Hexagonal,Other special-shaped shapes |
| 6 | Size error | OD error:±0.05mm Length error:0.1mm |
| 7 | Surface | Anodized,brushed,polished,mill finished,power coated,sand blast. |
| 8 | Temper |
O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc. |
| 9 | OEM service | Perforated, Cutting special size, Doing flatness, Surface treatment,etc |
| 10 | Payterm | Ex-work, FOB, CIF , CFR, etc |
| 11 | Payment | T/T, L/C, Western Union, etc |
| 12 | Delivery Time | Within 3 days for our stock size,10-20days for our production |
| 13 | Package |
Export standard package: bundled ,wooden box, suit for all kinds of transport, or be required |
| 14 | MOQ | 10kg |
| 15 | Sample | Free and available |
| 16 | Quality |
Mill Test Certification is supplied with shipment,Third Part Inspection(SGS/ROHS Certificate of Test) is acceptable. Tension levelled ,flat ,Free of defects like oil stain,Roll Marks,Waves,Dents scratches etc ,A+++ quality passed sgs and bv inspection |
| 17 | Application |
Construction filed, Ships building industry, Decoration, Industry,Manufacture, Machinery and hardware fields, etc |
| Garde | Chemical composition | ||||||||||
| Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Other | Al | |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | - | 0.05 | 0.03 | 0.03 | 99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | - | - | 0.05 | 0.03 | 0.03 | 99.6 |
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.05 | - | - | - | 0.1 | - | 0.15 | 99 | |
| 2A12 | 0.5 | 0.5 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | 0.1 | 0.3 | 0.15 | 0.1 | remains | |
| 2017 | 0.2-0.8 | 0.7 | 3.5-4.5 | 0.4-0.1 | 0.4-0.8 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 2014 | 0.5-1.2 | 0.7 | 3.9-5 | 0.4-1.2 | 0.2-0.8 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | - | - | - | 0.1 | - | 0.15 | remains |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0-1.5 | 0.2-0.6 | 0.1 | - | 0.25 | 0.1 | 0.15 | remains |
| 3105 | 0.6 | 0.7 | 0.3 | 0.3-0.8 | 0.2-0.8 | 0.2 | - | 0.4 | 0.1 | 0.15 | remains |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5-1.1 | 0.1 | - | 0.25 | - | 0.15 | remains |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | - | 0.1 | - | 0.15 | remains |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4-1 | 4.0-4.9 | 0.05-0.25 | - | 0.25 | 0.15 | 0.15 | remains |
| 5182 | 0.2 | 0.35 | 0.15 | 0.2-0.5 | 4.0-5.0 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | - | 0.2 | 0.15 | 0.15 | remains |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | - | 0.25 | 0.15 | 0.15 | remains |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | - | 0.1 | 0.1 | 0.15 | remains |
| 6082 | 0.7-1.3 | 0.5 | 0.1 | 0.4-1 | 0.6-1.2 | 0.25 | - | 0.2 | 0.1 | 0.15 | remains |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-5.6 | 0.2 | 0.15 | remains | |
FAQ
Q1: How do we trust your company?
A: We specialise in steel production and sales for years as golden supplier on Alibaba, headquarters locates in WUXI, JIANGSU Province, you are welcome to investigate in any ways, by all means, you could place an order in Alibaba with trade assurance which could secure your payment.
Q2: How can we guarantee quality?
A: 1 ). We can provide samples for free.We can send the samples by TNT,DHL,FEDEX,EMS,UPS or to your warehouse. 2 ). Always a pre-production sample before mass production. 3 ). Always final Inspection before shipment.
Q3: Do you have products in stock?
A: There are 10000 tons stock for various size.plsease inform us what model you need, we will send stock details to you.
Q4: How long will it take to produce my order?
A: Our normal produce time is 7-25 working days,depend on your order.
Q5: How much will the shipping cost be?
A: This will depend on the size and weight of your order and the method of shipping.
Q6: Can you help me find the shipping company?
A: Of course, if you don't work with a shipping company.We have a long-term cooperation of the transport team can provide you with lower prices, better service.
Q7: Will our goods be damaged during the long-distance transport? How to avoid it?
A: No damage, we will affix a low viscosity protective film on the surface of the product, effectively avoid scratches, easy to uncover when using, and will not leave stains on the surface.For long distance transportation we have professional experience,familiar with the packaging and arrangement of the goods, let the goods safely arrive at your destination.
Q8: Why should you buy from us not from other suppliers?
A: 1 ). Source manufacturers, leading equipment, excellent team skills. 2 ). Low price, fast delivery and excellent quality, good service. 3 ). Professional technical solution.
