3003 4032 Alumnum Round Bar 5A02 Hexagonal Aluminum Extrusion
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | haiwo |
| Model Number | 4032 |
| Minimum Order Quantity | 1000 kilograms |
| Price | $3.00/kilograms 1000-4999 kilograms |
| Packaging Details | Export standard package: bundled ,wooden box, suit for all kinds of transport,or be required |
| Delivery Time | 10-45 work days |
| Payment Terms | T/T |
| Supply Ability | 25000 Ton/Tons per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 5A02 Aluminum Bar | Temper | O - H112, T3-T8 |
|---|---|---|---|
| Grade | 5000 Series | Al (Min) | 90 |
| Ultimate Strength (≥ MPa) | 270 | Yield (≥ MPa) | 120 |
| Hardness | 45-75 | Application | Engineering, Turning, Parts, Mechanical Processing |
| High Light | 4032 Aluminum Round Bar,3003 Aluminum Round Bar,5A02 Hexagonal Aluminum Extrusion |
||
You can tick the products you need and communicate with us in the message board.
| Al (min) | 90% | |
|---|---|---|
| Length | 0-6000mm, 1m~12m, 300-12000MM, Customizable | |
| Price term | T/T | |
| Technique | Extruded, Cold Drawn, Forging |
Product Description
5A02 Aluminum Bar Round Square Extrusion Hexagonal Rod Aluminium Profile
According to the different metal elements contained in aluminum rods, aluminum rods can be roughly divided into 8 categories, that is, 9 series:
① 4000 series aluminum rod represents 4A01 4000 series aluminum rod belongs to the series with higher silicon content. The silicon content is usually between 4.5 and 6.0%. Belongs to construction materials, mechanical parts, forging materials, welding materials; Low melting point, good corrosion resistance, heat resistance, wear resistance.
② 5000 series aluminum rod represents 5052, 5005, 5083, 5A05 series. 5000 SERIES ALUMINUM ROD belongs to the more commonly used alloy aluminum rod series, the main element is magnesium, magnesium content between 3-5%. Can also be called aluminum magnesium alloy. The main characteristics are low density, high tensile strength, high elongation. The weight of aluminum-magnesium alloy is lower than that of other series under the same area, and it is widely used in conventional industry.
③ 6000 series aluminum rod represents 6061, 6063 mainly contains magnesium and silicon two elements, suitable for corrosion resistance, oxidation requirements of high applications. Good usability, easy coating, good processing.
④ 7000 series aluminum rod on behalf of 7075 mainly contains zinc elements. Also belongs to the aviation series, is aluminum magnesium zinc copper alloy, is a heat treatable alloy, belongs to the super hard aluminum alloy, has good wear resistance.
8000 series aluminum rod is more commonly used for 8011 belongs to other series, most applications for aluminum foil.
Specification
|
Garde
|
Si
|
Fe
|
Cu
|
Mn
|
Mg
|
Cr
|
Zn
|
Ti
|
Al
|
|
5A02
|
0.4
|
0.4
|
0.1
|
0.15-0.4
|
2.0-2.8
|
-
|
-
|
0.15
|
remains
|
Quality Characteristics
|
Brand
|
Tensile strength
|
Yield strength
|
Hardness
|
Elongation
|
|
5A02
|
≥270Mpa
|
≥120MPa
|
HB45-75
|
more than12
|
| Aluminium Bar/Aluminum Flat Bar /Aluminum Square Bar/ Rod | ||
| 1 | Production Standard | ASTM, AISI,EN,DIN,JIS,GOST,GB,etc |
| 2 | Material |
a) 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. g)7000 Series:7075,7475 |
| 3 | Outer diameter | 2mm-800mm |
| 4 | Length | 50mm-12000mm or cut as the customer’s request |
| 5 | Shape | Round, Square, Rectangular, Oval, Hexagonal,Other special-shaped shapes |
| 6 | Size error | OD error:±0.05mm Length error:0.1mm |
| 7 | Surface | Anodized,brushed,polished,mill finished,power coated,sand blast. |
| 8 | Temper |
O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc. |
| 9 | OEM service | Perforated, Cutting special size, Doing flatness, Surface treatment,etc |
| 10 | Payterm | Ex-work, FOB, CIF , CFR, etc |
| 11 | Payment | T/T, L/C, Western Union, etc |
| 12 | Delivery Time | Within 3 days for our stock size,10-20days for our production |
| 13 | Package |
Export standard package: bundled ,wooden box, suit for all kinds of transport, or be required |
| 14 | MOQ | 10kg |
| 15 | Sample | Free and available |
| 16 | Quality |
Mill Test Certification is supplied with shipment,Third Part Inspection(SGS/ROHS Certificate of Test) is acceptable. Tension levelled ,flat ,Free of defects like oil stain,Roll Marks,Waves,Dents scratches etc ,A+++ quality passed sgs and bv inspection |
| 17 | Application |
Construction filed, Ships building industry, Decoration, Industry,Manufacture, Machinery and hardware fields, etc |
| Garde | Chemical composition | ||||||||||
| Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Other | Al | |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | - | 0.05 | 0.03 | 0.03 | 99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | - | - | 0.05 | 0.03 | 0.03 | 99.6 |
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.05 | - | - | - | 0.1 | - | 0.15 | 99 | |
| 2A12 | 0.5 | 0.5 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | 0.1 | 0.3 | 0.15 | 0.1 | remains | |
| 2017 | 0.2-0.8 | 0.7 | 3.5-4.5 | 0.4-0.1 | 0.4-0.8 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 2014 | 0.5-1.2 | 0.7 | 3.9-5 | 0.4-1.2 | 0.2-0.8 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | - | - | - | 0.1 | - | 0.15 | remains |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0-1.5 | 0.2-0.6 | 0.1 | - | 0.25 | 0.1 | 0.15 | remains |
| 3105 | 0.6 | 0.7 | 0.3 | 0.3-0.8 | 0.2-0.8 | 0.2 | - | 0.4 | 0.1 | 0.15 | remains |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5-1.1 | 0.1 | - | 0.25 | - | 0.15 | remains |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | - | 0.1 | - | 0.15 | remains |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4-1 | 4.0-4.9 | 0.05-0.25 | - | 0.25 | 0.15 | 0.15 | remains |
| 5182 | 0.2 | 0.35 | 0.15 | 0.2-0.5 | 4.0-5.0 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | - | 0.2 | 0.15 | 0.15 | remains |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | - | 0.25 | 0.15 | 0.15 | remains |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | - | 0.1 | 0.1 | 0.15 | remains |
| 6082 | 0.7-1.3 | 0.5 | 0.1 | 0.4-1 | 0.6-1.2 | 0.25 | - | 0.2 | 0.1 | 0.15 | remains |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-5.6 | 0.2 | 0.15 | remains | |
FAQ
Q1: How do we trust your company?
A: We specialise in steel production and sales for years as golden supplier on Alibaba, headquarters locates in WUXI, JIANGSU Province, you are welcome to investigate in any ways, by all means, you could place an order in Alibaba with trade assurance which could secure your payment.
Q2: How can we guarantee quality?
A: 1 ). We can provide samples for free.We can send the samples by TNT,DHL,FEDEX,EMS,UPS or to your warehouse. 2 ). Always a pre-production sample before mass production. 3 ). Always final Inspection before shipment.
Q3: Do you have products in stock?
A: There are 10000 tons stock for various size.plsease inform us what model you need, we will send stock details to you.
Q4: How long will it take to produce my order?
A: Our normal produce time is 7-25 working days,depend on your order.
Q5: How much will the shipping cost be?
A: This will depend on the size and weight of your order and the method of shipping.
Q6: Can you help me find the shipping company?
A: Of course, if you don't work with a shipping company.We have a long-term cooperation of the transport team can provide you with lower prices, better service.
Q7: Will our goods be damaged during the long-distance transport? How to avoid it?
A: No damage, we will affix a low viscosity protective film on the surface of the product, effectively avoid scratches, easy to uncover when using, and will not leave stains on the surface.For long distance transportation we have professional experience,familiar with the packaging and arrangement of the goods, let the goods safely arrive at your destination.
Q8: Why should you buy from us not from other suppliers?
A: 1 ). Source manufacturers, leading equipment, excellent team skills. 2 ). Low price, fast delivery and excellent quality, good service. 3 ). Professional technical solution.
