H112 3003 Aluminum Coil Strip Industrial T651 High Temperature Aluminum Foil
Place of Origin | Jiangsu, China |
---|---|
Brand Name | haiwo |
Model Number | 3003 |
Minimum Order Quantity | 1000 kilograms |
Price | $3.00/kilograms |
Packaging Details | Export standard package: bundled ,wooden box, suit for all kinds of transport,or be required |
Delivery Time | 10-45 work days |
Payment Terms | T/T |
Supply Ability | 25000 Ton/Tons per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Name | 3003 Aluminum Roll | Grade | 3000 Series |
---|---|---|---|
Tolerance | ±1% | Thickness | 0.006-0.2mm,1.0-12.0mm |
Packing | Wooden Cases,Standard Packing | Application | Widely Used,Food Packing,manufacture,aluminum Foil Pull Tab Strip For Milk Carton Cap,High Temperature |
Certification | ISO,FDA,ISO9001,SGS,ASTM B209 | Sample | Available And Free |
High Light | H112 3003 Aluminum Coil,3003 Aluminum Coil,Industrial Aluminum Coil Strip T651 |
Structure | AL/PE, OP + AL + PE, PET/AL/PE | |
---|---|---|
Treatment | Coated, Composited, Other, Embossed, mill finish | |
Type | Roll, Die Cut Piece, aluminum foil | |
Temper | Soft, O, Hard, H22, H18 |
3003 Aluminum Roll Household Industrial Aluminum Coil Strip H112 H24 T4 T6 T651
Aluminum coil is widely used in electronics, packaging, construction, machinery and other aspects, China's aluminum coil production enterprises, the production process has caught up with the developed countries, according to the metal elements aluminum coil contains, aluminum coil can be divided into 9 major: 1000 series; The 2000 series; The 3000 series; The 4000 series; The 5000 series; The 6000 series; The 7000 series; The 8000 series; The 9000 series.
Product Classification:① Commonly used aluminum roll alloy grades are 1050, 1060, 1070, 1100, 3003, 3004, 5005, 5052, 8011 and so on. Common states are O state and H state. O for soft state, H for hard state. O and H can be followed by numbers to indicate the degree of softness and hardness, and the degree of annealing.
② The specific uses of aluminum roll are mainly: transformer aluminum roll (transformer aluminum foil), high frequency welding hollow aluminum roll with aluminum roll, fin radiator with aluminum roll, cable with aluminum roll, stamping with aluminum roll, aluminum edge with aluminum roll, etc.
③ Aluminum alloy roll categories are: pure aluminum roll, transformer aluminum roll, super hard aluminum roll, soft aluminum roll, semi-hard aluminum roll, rust resistant aluminum roll.
Brand
|
Al
|
Si
|
Fe
|
Cu
|
Mn
|
Mg
|
Cr
|
Zn
|
Ti
|
3003
|
remains
|
0.6
|
0.7
|
0.05-0.2
|
1-1.5
|
-
|
-
|
0.1
|
-
|
Mechanical properties of 3003 aluminum
|
|
|
|
|
||||
Tensile strength
|
≥140-200Mpa
|
|
|
|
||||
Yield strength
|
≥115MPa
|
|
|
|
||||
Hardness
|
HB35-45
|
|
|
|
||||
Elongation
|
12
|
|
|
|
Aluminium Coil / Aluminium Alloy Coil | ||
1 | Production Standard | ASTM, AISI,EN,DIN,BS,JIS,GOST,GB,etc |
2 | Material |
a) 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. g)7000 Series:7075,7475 |
3 | Width | 20mm-2500mm or as the customer’s request |
4 | Length/weight | Length:Any length. weight:50-10000kg/coil, As the customer’s request |
5 | Thickness | Sheet:0.05-10mm; Foil:0.001-0.5 ; Strip:0.01-3mm |
6 | Size error | Thickness error:±0.005mm Width error:0.1mm |
7 | Surface | Coated, Mill, Bright, Polished, Embossed,Brushed, Anodized,sand blast, checkered,embossed, etching,etc |
8 | Temper |
O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc. |
9 | OEM service | Perforated, Cutting special size, Doing flatness, Surface treatment,etc |
10 | Payterm | EXW, FOB, CIF , CFR, etc |
11 | Payment | T/T, L/C, Western Union, etc |
12 | Delivery Time | Within 3 days for our stock size,10-20days for our production |
13 | Package |
Export standard package: bundled ,wooden box, suit for all kinds of transport, or be required |
14 | MOQ | 10kg |
15 | Sample | Free and available |
16 | Quality |
Mill Test Certification is supplied with shipment,Third Part Inspection(SGS/ROHS Certificate of Test) is acceptable. Tension levelled ,flat ,Free of defects like oil stain,Roll Marks,Waves,Dents scratches etc ,A+++ quality passed sgs and bv inspection |
17 | Application |
Construction filed, Ships building industry, Decoration, Industry,Manufacture, Machinery and hardware fields, et |
