H112 H24 Alloy Aluminium Coil Strip T8 Hard Tempered Aluminum Foil Roll

      Aluminum coil is a metal product for flying shearing after calendering and drawing Angle processing by casting and rolling machine.

     Classification of aluminum coil:

       ① 1000 series:Represents 1000 series aluminum plate is also known as pure aluminum plate, in all series, 1000 series belongs to a series with the largest amount of aluminum. The purity can reach more than 99.00%. It is the most commonly used series in conventional industry at present. Most of the 1050 and 1060 series are in circulation.

       ② 2000 series:On behalf of 2A16 (LY16) 2A06 (LY6) 2000 series aluminum plate is characterized by high hardness, with the highest content of copper, about 3-5%. 2000 series aluminum plate belongs to aviation aluminum material, which is not often used in conventional industry.

       ③ 3000 series:Represents 3003, 3003, 3A21. It can also be called rust-proof aluminum plate in China 3000 series aluminum production process is excellent. 3000 series aluminum plate is made of manganese as the main component. The content is between 1.0 and 1.5. It is a series with better rust prevention function. Commonly used in air conditioning, refrigerator, car bottom and other humid environment, is a relatively common alloy series.

       ④ 4000 series:The aluminum plate representing 4A01 4000 series belongs to the series with higher silicon content. The silicon content is usually between 4.5 and 6.0%. Belongs to construction materials, mechanical parts, forging materials, welding materials; Low melting point, good corrosion resistance Product Description: Heat resistance, wear resistance.

Aluminium Coil / Aluminium Alloy Coil
1	Production Standard	ASTM, AISI,EN,DIN,BS,JIS,GOST,GB,etc
2	Material	a) 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. b) 2000 Series: 2014, 2024, etc. c) 3000 Series: 3003, 3004, 3005, 3104, 3105, 3A21, etc. d) 4000 Series: 4045, 4047, 4343, etc. e) 5000 Series: 5005, 5052, 5083, 5086, 5154, 5182, 5454, 5754, 5A06, etc. f) 6000 Series: 6061, 6063, 6082, 6A02, etc. g)7000 Series:7075,7475
3	Width	20mm-2500mm or as the customer’s request
4	Length/weight	Length:Any length. weight:50-10000kg/coil, As the customer’s request
5	Thickness	Sheet:0.05-10mm; Foil:0.001-0.5 ; Strip:0.01-3mm
6	Size error	Thickness error:±0.005mm Width error:0.1mm
7	Surface	Coated, Mill, Bright, Polished, Embossed,Brushed, Anodized,sand blast, checkered,embossed, etching,etc
8	Temper	O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc.
9	OEM service	Perforated, Cutting special size, Doing flatness, Surface treatment,etc
10	Payterm	EXW, FOB, CIF , CFR, etc
11	Payment	T/T, L/C, Western Union, etc
12	Delivery Time	Within 3 days for our stock size,10-20days for our production
13	Package	Export standard package: bundled ,wooden box, suit for all kinds of transport, or be required
14	MOQ	10kg
15	Sample	Free and available
16	Quality	Mill Test Certification is supplied with shipment,Third Part Inspection(SGS/ROHS Certificate of Test) is acceptable.  Tension levelled ,flat ,Free of defects like oil stain,Roll Marks,Waves,Dents scratches etc ,A+++ quality passed sgs and bv inspection
17	Application	Construction filed, Ships building industry, Decoration, Industry,Manufacture, Machinery and hardware fields, etc



Mechanical Property
ALUMINUM ALLOY	Grade	Normal Temper	Temper	Tensile Strength N/mm²	Yield Strength N/mm²	Elongation%		Brinell Hardness HB
						Plate	Bar
1XXX	1050	O,H112,H	O	78	34	40	-	20
	1060	O,H112,H	O	70	30	43	-	19
Al-Cu (2XXX)	2017	O,T3,T4,T6,T8	T851	450	350	10	-	-
	2024	O,T4	T4	470	325	20	17	120
Al-Mn (3XXX)	3003	O,H112,H	O	110	40	30	37	28
	3004	O,H112,H	O	180	70	20	22	45
Al-Si (4XXX)	4032	O,T6,T62	T6	380	315	-	9	120
Al-Mg (5XXX)	5052	O,H112,H	H34	260	215	10	12	68
	5083	O,H112,H	O	290	145	-	20	-
Al-Mg-Si (6XXX)	6061	O,T4,T6,T8	T6	310	275	12	15	95
	6063	O,T1,T5,T6,T8	T5	185	145	12	-	60
Al-Zn-Mg (7XXX)	7003	T5	T5	315	255	15	-	85
	7075	O,T6	T6	570	505	11	9	150
