3105 3003 Zinc Coated Aluminium Sheet 5052 Aluminum Sheet Metal Fabrication
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | haiwo |
| Model Number | 3105 |
| Minimum Order Quantity | 1000 kilograms |
| Price | $3.50/kilograms |
| Packaging Details | Export standard package: bundled ,wooden box, suit for all kinds of transport,or be required |
| Delivery Time | 10-45 work days |
| Payment Terms | T/T |
| Supply Ability | 25000 Ton/Tons per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 3105 Aluminum Plate | Grade | 3000 Series |
|---|---|---|---|
| Temper | O-H112,T3-T8 | Application | Aviation Industry, Aircraft Manufacturing |
| Standard | ASTM AISI JIS DIN GB | MOQ | 1000kg |
| Width | 50-2500mm | Tolerance | ±1% |
| High Light | 3105 Zinc Coated Aluminium Sheet,3003 Zinc Coated Aluminium Sheet,5052 Aluminum Sheet Metal Fabrication |
||
You can tick the products you need and communicate with us in the message board.
| Processing service | bending,cutting,welding,punching | |
|---|---|---|
| Surface | Bright,anodizing,polish,mirror | |
| Size | As customer require | |
| Loading port | SHANGHAI PORT |
Product Description
3105 1100 3003 5052 6061 Alloy Aluminum Plate Aluminum Sheet Mental Fabrication
Aluminum plate refers to the rectangular plate made of aluminum ingot rolling. It can be divided into pure aluminum plate, alloy aluminum plate, thin aluminum plate, medium-thick aluminum plate and patterned aluminum plate.
Type:① Drawing aluminum plate: The manufacturing process of repeatedly scraping the aluminum plate out of the line with sandpaper. The main process is divided into three parts: deester, sand mill and water washing. In THE PROCESS OF aluminum wire drawing, the special film technology after ANODIzing can make the surface of aluminum plate generate a skin film layer containing the metal component, clearly show every tiny silk mark, so as to make the metal matte with a fine hair luster.
② Aluminum oxide plate: the aluminum plate is placed in the corresponding electrolyte (such as sulfuric acid, chromic acid, oxalic acid, etc.) as the anode, under the action of specific conditions and applied current, the aluminum plate formed by electrolysis. The anodic aluminum plate is oxidized to form a thin layer of alumina on the surface, the thickness of which is 5 ~ 20 microns, and the hard anodic film can reach 60 ~ 200 microns.
③ PS aluminum plate (advertising aluminum plate also known as printing zinc plate, newspaper plate) : that is, on the back of the printing pattern thickness of the aluminum plate is 025 or 03 material.
Specification
|
Brand
|
Si
|
Fe
|
Cu
|
Mn
|
Mg
|
Cr
|
Zn
|
Ti
|
AL
|
|
3105
|
0.6
|
0.7
|
0.3
|
0.3-0.8
|
0.3-0.8
|
0.2
|
0.4
|
0.1
|
remains
|
Quality Characteristics
|
Brand
|
Tensile strength
|
Yield strength
|
Hardness
|
Elongation
|
|
3105
|
≥140-200Mpa
|
≥115MPa
|
HB35-45
|
12
|
| Aluminium Sheet / Aluminium Plate/Strip/Foil | ||
| 1 | Production Standard | ASTM, AISI,EN,DIN,JIS,GOST,GB,etc |
| 2 | Material | 1000, 2000, 3000, 4000, 5000, 6000, 7000, 8000 |
| 3 | Width | 50mm-2500mm or as the customer’s request |
| 4 | Longth | 50mm-8000mm or as the customer’s request |
| 5 | Thickness | Foil:0.001-0.5 ; Strip:0.01-3mm ; Sheet:0.1-6mm ; Plate:6.0-500mm |
| 6 | Size error | Thickness error:±0.005mm Width error:0.1mm |
| 7 | Surface | Coated, Embossed,Brushed, polished, Anodized,etc |
| 8 | Temper |
O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc. |
| 9 | OEM service | Perforated, Cutting special size, Doing flatness, Surface treatment,etc |
| 10 | Payterm | Ex-work, FOB, CIF , CFR, etc |
| 11 | Payment | T/T, L/C, Western Union, etc |
| 12 | Delivery Time | Within 3 days for our stock size,10-20days for our production |
| 13 | Package |
Export standard package: bundled ,wooden box, suit for all kinds of transport, or be required |
| 14 | MOQ | 10kg |
| 15 | Sample | Free and available |
| 16 | Quality | Certificate of Test,SGS,ISO9001,TVE |
| 17 | Export To |
Singapore,Indonesia,Ukraine,Saudi Arabia,Spain,Brazil,Thailand,Korea,India, Egypt,Kuwait,Oman,Viet Nam,South Africa,Dubai,England,Holland,Russia,etc |
| 18 | Application |
Construction filed, Ships building industry, Decoration, Industry,Manufacture, Machinery and hardware fields, etc |
| Garde | Chemical composition | ||||||||||
| Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Other | Al | |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | - | 0.05 | 0.03 | 0.03 | 99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | - | - | 0.05 | 0.03 | 0.03 | 99.6 |
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.05 | - | - | - | 0.1 | - | 0.15 | 99 | |
| 2A12 | 0.5 | 0.5 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | 0.1 | 0.3 | 0.15 | 0.1 | remains | |
| 2017 | 0.2-0.8 | 0.7 | 3.5-4.5 | 0.4-0.1 | 0.4-0.8 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 2014 | 0.5-1.2 | 0.7 | 3.9-5 | 0.4-1.2 | 0.2-0.8 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | - | - | - | 0.1 | - | 0.15 | remains |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0-1.5 | 0.2-0.6 | 0.1 | - | 0.25 | 0.1 | 0.15 | remains |
| 3105 | 0.6 | 0.7 | 0.3 | 0.3-0.8 | 0.2-0.8 | 0.2 | - | 0.4 | 0.1 | 0.15 | remains |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5-1.1 | 0.1 | - | 0.25 | - | 0.15 | remains |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | - | 0.1 | - | 0.15 | remains |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4-1 | 4.0-4.9 | 0.05-0.25 | - | 0.25 | 0.15 | 0.15 | remains |
| 5182 | 0.2 | 0.35 | 0.15 | 0.2-0.5 | 4.0-5.0 | 0.1 | - | 0.25 | 0.15 | 0.15 | remains |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | - | 0.2 | 0.15 | 0.15 | remains |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | - | 0.25 | 0.15 | 0.15 | remains |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | - | 0.1 | 0.1 | 0.15 | remains |
| 6082 | 0.7-1.3 | 0.5 | 0.1 | 0.4-1 | 0.6-1.2 | 0.25 | - | 0.2 | 0.1 | 0.15 | remains |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-5.6 | 0.2 | 0.15 | remains | |
